1. Application:
It’s special for 3~7 cores twisting with wrapping.
2-Parameters:
| Machine type | SY-630 | SY-800 | SY-1000 | SY-1250 |
| Pay-off bobbin dia. | 400-500-630mm | |||
| Take-up bobbin dia. | 630mm | 800mm | 1000mm | 1250mm |
| Applicable wire dia. | 0.6-3.0mm | 0.6-3.0mm | 1.0-5.0mm | 1.0-5.0mm |
| MAX. lay-up dia. | 15mm | 20mm | 25mm | 30mm |
| Twisting pitch | 20mm-200mm | 30mm-300mm | 30mm-350mm | 30mm-350mm |
| No.of rotate | 1000r/min | 800r/min | 600r/min | 550r/min |
| Take-up tension | Pneumatic | |||
| Traversing distance | 2mm-12mm | 3mm-20mm | 3mm-30mm | 3mm-30mm |
| Twisting direction | S /Z | |||
| Wrapping type | center/side wrapping | |||
3.Advantages:
1) More stability, high production efficiency, low noise and easy to operation.
2) Spring bow can prolong the life.
3) Take-up tension is controlled by magnetic powder clutch or mechanical type.
4) If the wire breaks, the machine can stop automatically.
4.Delivery time: 45 working days
5.After-sell service:
Engineer will be dispatched at needed.
The buyer provides engineer’s round trip flight tickets, board and lodging, the security as well as each person of daily wage.
6.Guarantee: 12 months since shipping date(exclude easily wearing part)
Click here to find out more about different types of Single Twisting Machine
